| Product Name |
Poseidon Vistek
ARGB 360 |
Poseidon Vistek
ARGB 240 |
Poseidon Vistek
ARGB 360(White) |
Poseidon Vistek
ARGB 240(White) |
| CPU Socket |
Intel |
LGA1851 / LGA1700 / LGA1200 / LGA115X / LGA1366 |
| AMD |
AM5 / AM4 / AM3 / AM2 / FM2 / FM1 |
| Water Block & Pump |
Dimensions (WxDxH) |
φ70 x 59mm |
| Cold Plate Material |
Copper |
| Pump Speed |
2700 ± 10% RPM |
| Rated Voltage |
12 VDC |
| Rated Current |
0.2 A |
| Power Consumption |
2.4W |
| Connector |
Pump: 2510-3Pin
Power supply : USB Connector |
| Radiator |
Dimensions (WxDxH) |
Poseidon Vistek ARGB 240 : 272 x 121 x 27mm
Poseidon Vistek ARGB 360 : 392 x 121 x 27mm |
| Material |
Aluminium Alloy |
| Tubing |
Length |
390±5mm |
| Fans |
Fan Model |
Unity 360 ARGB |
Unity 240 ARGB |
Unity 360 ARGB (White) |
Unity 240 ARGB (White) |
| Dimensions (WxDxH) |
363.3 x 125 x 25 mm |
243.6 x 125 x 25 mm |
363.3 x 125 x 25 mm |
243.6 x 125 x 25 mm |
| Fan Speed |
700-2500 RPM ±10% |
| Air Flow |
78.2 CFM |
| Air Pressure |
5.4 mmH2O |
| Acoustic Noise |
38 dB(A) |
| Power Consumption |
Unity 360 ARGB :
10.2 W (Fan) / 8W (LED) |
Unity 240 ARGB :
6.72W (Fan) / 5 W (LED) |
Unity 360 ARGB (White) :
10.2 W (Fan) / 8W (LED) |
Unity 240 ARGB (White) :
6.72W (Fan) / 5 W (LED) |
| Rated Current |
0.85 A (Fan) / 1.6 A (LED) |
0.56 A (Fan) / 1.0 A (LED) |
0.85 A (Fan) / 1.6 A (LED) |
0.56 A (Fan) / 1.0 A (LED) |
| Rated Voltage |
12 VDC (Fan) / 5 VDC (LED) |
| Connector & Control |
Fan : 2510-4Pin PWM
Lights : 5V-3Pin ARGB |
